Description
Digital 8 LPM pump alternately inflates and deflates air bladders ••• 5" air mattress on 3" densified foam base ••• Low air loss helps keep skin cool and dry ••• Adjustable LED weight settings ••• Fluid resistant, nylon cover ••• Alternating pressure mattress helps prevent and treat pressure sores •• Supports up to 400 lbs. ••• Mattress dimensions: 80"L x 36"W x 8"H
The Protekt® Aire 5000DX is the 1st defense for facilities to treat pressure ulcers stages I-IV. The high volume user friendly pump combines low air loss and alternating pressure in one unit. The air flow and pressure range can be customized according to each individual patient's weight. The "static" mode provides a firm support for easy patient transfer.
PROTEKT® AIRE 5000DX DIGITAL PUMP FEATURES
- Digital Pump with Auto Compressor Sleep Technology (ACST) shuts off compressor at desired pressure level extending pump life cycle
- Digital adjustable LED weight settings allows pressure to be customized according to each patient’s therapeutic requirements
- Pump alternately inflates and deflates air cells in mattress overlay to create different patient support points
- Provides low air loss and alternating pressure therapies in one system
- 8 LPM pump alternately inflates and deflates air bladders
- Low air loss function helps keep skin cool and dry
- Preset 10 minute alternating cycle time
- Static function for safe and easy patient transfer
- Visual low pressure alarm
- Adjustable hanging brackets
- Lighted On/Off switch and hanging bed hooks
- Limited 2 year warranty
MATTRESS & COVER FEATURES
- 5” mattress with 3” densified fiber base provides a safety support base in case of power failure
- 17 individual air bladders
- Laser holes in air bladders allow low air loss to keep the patient cool and dry
- Pillow top, static head section prevents head and neck from unnecessary movement during alternating mode
- Nylon top cover is fluid resistant, anti-microbial/anti-bacterial and quilted for added comfort
- Transport connector locks in air for easy patient transfers
- CPR valve provides rapid deflation of mattress
- Kink resistant tubing
- Mattress dimensions: 36”W x 80”L x 8"H
- Easy to set up and operate
- Weight capacity is 400 lbs.
- Limited 2 year warranty
CLICK HERE FOR OWNER'S MANUAL
To speak with a customer service representative, call 1-800-956-6616
- Alternating pressure mattress helps prevent and treat pressure sores
- 5” air mattress with 3” densified fiber foam base in case of power failure
- Digital 8 LPM pump alternately inflates and deflates air bladders
- Low air loss function helps keep skin cool and dry
- Digital adjustable LED weight settings allows pressure to be customized
- Mattress dimensions: 80"L x 36"W x 8"H
- Supports up to 400 lbs.
Specifications
| Power Supply: | 120 V, 50Hz |
| Air Output: | 8 LPM |
| Pressure Range: | 20 mmHg - 50 mmHg |
| Cycle Time: | 10 min. |
| Fuse: | 250 V, 1 A |
| Pump Dimensions: | 10.6" x 6" x 4" |
| Pump Weight: | 3.5 lbs. |
| Mattress Dimensions: | 80"L x 36"W x 8"H |
| Mattress Construction: | Top Cover: Quilted Nylon/ PU Air Cells: 17 ea, Nylon/ PVC, 5"H Botton Cover: Nylon/ PVC w/ 3"H Foam |
| Weight Capacity: | 400 lbs. |
| Limited Warranty: | Pump: 2 years Mattress: 2 years |
Additional Information
Mattress Features: |
Alternating Pressure |
Mattress Features: |
Low Air Loss |
Mattress Features: |
Foam Base |
Mattress Height: |
8" |
Mattress Width: |
35" - 36" |
Mattress Length: |
80" |
User Weight: |
Up to 400 lbs. |
Pump Flow Rate: |
8 - 12 lpm |
Pump Features: |
Digital Display |
